Dynamic tuning of high-<i>Q</i> quasi-bound states in continuum driven by liquid crystal

YANG Fei; ZHANG Binglin; SHENG Miaomiao; JIN Lufan; YAO Jianquan

doi:10.7498/aps.74.20250337

Abstract

Optical systems based on bound states in the continuum (BIC) generally possess higher quality factor (Q) values and narrower operational linewidths than traditional photonic crystals or metasurfaces. The higher Q values offer extensive possibilities for high-performance optoelectronic devices. However, the narrower linewidths often pose challenges in practical applications, as fabrication errors during production inevitably lead to discrepancies between real optical devices and their ideal designs, which results in mismatches between actual and ideal operating wavelengths. To solve this problem, we explore the dynamic tuning effect of liquid crystal (LC) on quasi-bound states in the continuum (q-BIC) so as to compensate for wavelength shifts caused by fabrication errors. A photonic crystal slab with cross-shaped holes serves as the platform for generating q-BIC. Compared with the modulation induced by the tilt angles of incident light on q-BIC, LC has a less influence on the system’s Q factor when the same operational wavelength is shifted. For instance, shifting the central wavelength λ₀ of q-BIC by 5.32 nm by using a tilted incident angle results in the Q factor decreasing to 24.16% (from 3809.05 to 920.28). Whereas shifting the central wavelength λ₀ by 5.63 nm through the tilt angle θ of LC leads Q factor to increase 14.27% (from 3809.05 to 4352.65). This demonstrates the significant potential of LC dynamic tuning in high-Q and ultra-narrowband q-BIC devices. Finally, the mechanism of LC within the q-BIC system is discussed. The smaller influence of LC on the Q factor is attributed to its minimal disruption of the q-BIC system’s symmetry. Although LC also affects system symmetry within the cross-shaped holes, after adjusting the asymmetry parameters of the system, the Q factor and the LC tuning process can be well matched. The results of our research provides valuable references for carrying on extensive research on q-BIC.

Keywords:

Authors and contacts

Corresponding author: JIN Lufan, jlfking@zjitc.edu.cn

Funds: Project supported by the Teacher Professional Development Program for Domestic Visiting Scholars from the Education Commission of Zhejiang Province, China (Grant No. FX2024188) and the Science and Technology Innovation Project for Teachers at Zhejiang Industry and Trade Vocational College, China (Grant No. Z20240027).

FullText HTML

References

[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]

Cited By

DownLoad: Full-Size Img PowerPoint

DownLoad: Full-Size Img PowerPoint

DownLoad: Full-Size Img PowerPoint

DownLoad: Full-Size Img PowerPoint

DownLoad: Full-Size Img PowerPoint

map

[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]

[1]	ZHANG Yunhao, HE Xiao, YING Jiahe, LIU Donglin, TAO Guangyi, DAI Yuchen, DANG Zhibo, FANG Zheyu. Characterization and control of quasi-bound states in the continuous in Si₃N₄ photonic crystals. Acta Physica Sinica, 2025, 74(18): 184204. doi: 10.7498/aps.74.20250757
[2]	Meng Xiang-Yu, Li Tao, Yu Bin-Bin, Tai Yong-Hang. Exploring the tuning mechanism of multipolar quasi-continuous domain bound states in tetramer metasurface. Acta Physica Sinica, 2024, 73(10): 107801. doi: 10.7498/aps.73.20240272
[3]	Liu Hui-Gang, Zhang Xiang-Yu, Nan Xue-Ying, Zhao Er-Gang, Liu Hai-Tao. All-dielectric metasurface two-parameter sensor based on quasi-bound states in continuum. Acta Physica Sinica, 2024, 73(4): 047802. doi: 10.7498/aps.73.20231514
[4]	Zhou Ming-Jie, Tan Hai-Yun, Zhou Yan, Zhuge Lan-Jian, Wu Xue-Mei. A tunable narrow-band plasma photonic crystal filter based on bound state. Acta Physica Sinica, 2021, 70(17): 175201. doi: 10.7498/aps.70.20210241
[5]	Du Qian, Chen Yi-Hang. Enhancing third-harmonic generation by quasi bound states in continuum in silicon nanoparticle arrays. Acta Physica Sinica, 2021, 70(15): 154206. doi: 10.7498/aps.70.20210332
[6]	Wang Zhi-Peng, Guan Bao-Lu, Zhang Feng, Yang Jia-Wei. Liquid crystal tunable vertical cavity surface emission laser with inner cavity sub-wavelength grating. Acta Physica Sinica, 2021, 70(22): 224208. doi: 10.7498/aps.70.20210957
[7]	Xing Rong, Xie Shuang-Yuan, Xu Jing-Ping, Yang Ya-Ping. Spontaneous emission from a V-type three-level atom in a dynamic photonic crystal. Acta Physica Sinica, 2017, 66(1): 014202. doi: 10.7498/aps.66.014202
[8]	Xing Rong, Xie Shuang-Yuan, Xu Jing-Ping, Yang Ya-Ping. Characteristics of the spontaneous emission field and spectrum of a two-level atom in a dynamic photonic crystal. Acta Physica Sinica, 2016, 65(19): 194204. doi: 10.7498/aps.65.194204
[9]	Geng Tao, Wu Na, Dong Xiang-Mei, Gao Xiu-Min. Tunable near-zero index of self-assembled photonic crystal using magnetic fluid. Acta Physica Sinica, 2016, 65(1): 014213. doi: 10.7498/aps.65.014213
[10]	Zhu Qi-Guang, Dong Xin-Yu, Wang Chun-Fang, Wang Ning, Chen Wei-Dong. Tunable filtering properties of the ployphyly photonic crystal with double local states. Acta Physica Sinica, 2015, 64(3): 034209. doi: 10.7498/aps.64.034209
[11]	Wang Jia-Lu, Du Mu-Qing, Zhang Ling-Li, Liu Yong-Jun, Sun Wei-Min. Transmission characteristics of photonic crystal fibers based on filling different kinds of liquid crystals. Acta Physica Sinica, 2015, 64(12): 120702. doi: 10.7498/aps.64.120702
[12]	Yang Fu-Zi. From plasmon to nanoplasmonics-the frontiers of modern photonics and the role of liquid crystals in tuneable nanoplasmonics. Acta Physica Sinica, 2015, 64(12): 124214. doi: 10.7498/aps.64.124214
[13]	Xing Rong, Xie Shuang-Yuan, Xu Jing-Ping, Yang Ya-Ping. Spontaneous emission from a two-level atom in a dynamic photonic crystal with an isotropic disoersion relation. Acta Physica Sinica, 2014, 63(9): 094205. doi: 10.7498/aps.63.094205
[14]	Chen Wei-Dong, Dong Xin-Yu, Chen Ying, Zhu Qi-Guang, Wang Ning. Analysis of the tunable filtering properties of a photonic crystal with symmetric dual defects. Acta Physica Sinica, 2014, 63(15): 154207. doi: 10.7498/aps.63.154207
[15]	Li Qian-Li, Wen Ting-Dun, Xu Li-Ping, Wang Zhi-Bin. Effect of uniaxial stress on photon localization of one-dimensional photonic crystal with a mirror symmetry. Acta Physica Sinica, 2013, 62(18): 184212. doi: 10.7498/aps.62.184212
[16]	Zhou Jian-Wei, Liang Jing-Qiu, Liang Zhong-Zhu, Tian Chao, Qin Yu-Xin, Wang Wei-Biao. Tunable two-dimensional photonic crystal cavity all-optical switching infiltrated with liquid-crystal. Acta Physica Sinica, 2013, 62(13): 134208. doi: 10.7498/aps.62.134208
[17]	Wang Chang-Hui, Zhao Guo-Hua, Chang Sheng-Jiang. Photonic-crystal-waveguide based Mach-Zehnder interferometer for terahertz switch and modulator. Acta Physica Sinica, 2012, 61(15): 157805. doi: 10.7498/aps.61.157805
[18]	He Zheng-Hong, Ye Zhi-Cheng, Li Zheng-Guang, Cui Qing-Yu, Su Yi-Kai. Compound photonic crystals with cholesteric liquid crystals sandwiched isotropic defect layers. Acta Physica Sinica, 2011, 60(3): 034213. doi: 10.7498/aps.60.034213
[19]	Zheng Zhi-Gang, Li Wen-Cui, Liu Yong-Gang, Xuan Li. Electrically tunable multiplexed grating with alternate liquid crystal-polymer structure. Acta Physica Sinica, 2008, 57(11): 7344-7348. doi: 10.7498/aps.57.7344
[20]	Yin Jian-Ling, Huang Xu-Guang, Liu Song-Hao, Hu She-Jun. Photonic crystal field-sensitive polarizer and switch modulated by nemaic liquid crystals. Acta Physica Sinica, 2006, 55(10): 5268-5276. doi: 10.7498/aps.55.5268
