WANG Bo; JIANG Hongxiang; ZHANG Lili; HE Jie

doi:10.7498/aps.74.20250776

Abstract

Al-Si alloys have been widely used in automotive, aerospace, electronics and communication industries due to their excellent castability, low thermal expansion, and good wear and corrosion resistance. However, the presence of coarse eutectic Si often results in relatively low thermal conductivity. With the rapid development of the electronics and communication industries, the requirements for thermal conductivity and mechanical properties of materials are increasing. In this study, the effects of heat treatment and minor Mg addition on the microstructure, mechanical properties, and thermal conductivity of Al-7Si alloys are systematically investigated.The results indicate that heat treatment at 300 ℃ after solution treatment promotes the spheroidization of eutectic Si and reduces the solid solubility of solute atoms in the aluminum matrix, thereby enhancing the thermal conductivity and reducing the hardness of the Al-7Si alloy. The three-step heat treatment process (solution treatment +300 ℃ treatment +180 ℃ treatment) not only facilitates the spheroidization of eutectic Si, but also induces the precipitation of nanoscale (Mg, Si) strengthening phases, further reducing the solid solubility of solute elements in the Al-7Si alloy with 0.4%Mg addition. After the three-step heat treatment, the Al-7Si-0.4Mg alloy reaches to 189 W/(m·K) in thermal conductivity and 73.5 HV in microhardness, respectively, which are increased by 11.2% and 62.6% respectively, compared with the as-cast Al-7Si alloy.According to the Wiedemann-Franz law and the Matthiessen-Fleming rule, the primary factors influencing the thermal conductivity of alloys are solute atoms in solid solution and secondary phases. In this study, a three-step heat treatment process is used to transform the plate-like eutectic silicon in the Al-7Si-0.4Mg alloy into fine spherical particles. Additionally, micrometer-sized silicon particles and nanoscale (Mg, Si) precipitates are induced within the alloy matrix. This microstructural modification simultaneously enhances the thermal conductivity and mechanical properties of the alloy. Our work is expected to inspire the design of Al-Si alloy with high strength and high conductivity.

Keywords:

Authors and contacts

Corresponding author: JIANG Hongxiang, hxjiang@imr.ac.cn ; HE Jie, jiehe@imr.ac.cn

Funds: Project supported by the Guangxi Science and Technology Program, China (Grant No. AA23023032), the National Natural Science Foundation of China (Grant Nos. 52174380, 51974288), and the Space Utilization System of China Manned Space Engineering (Grant No. KJZ-YY-NCL06).

FullText HTML

References

[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]

Cited By

DownLoad: Full-Size Img PowerPoint

Alloy	Mg	B	La	Sr	Fe	Si	Al
Al-7Si	0	0.024	0.04	0.02	0.25	7	Bal.
Al-7Si-0.4Mg	0.4	0.024	0.04	0.02	0.25	7	Bal.

DownLoad: CSV

Alloy	Process	Temperature/℃	Time
Al-7Si	SS	530	0 h, 0.5 h, 1 h, 1.5 h, 2 h
Al-7Si	HT	300	0 min, 20 min, 40 min, 60 min, 80 min, 100 min
Al-7Si- 0.4Mg	SS	530	0 h, 0.5 h, 1 h, 1.5 h, 2 h
	HT	300	0 min, 20 min, 40 min, 60 min, 80 min, 100 min
	LT	180	0 h, 6 h, 12 h

DownLoad: CSV

Heat treatment process	Thermal conductivity /(W·m^–1·K^–1)	Hardness /HV	Ultra tensile stress/MPa	Elongation/%
As-cast	162	60.9	169	6.25
SS1.5 h+HT60 min	185	62.9	176	8
SS1.5 h+HT60 min+LT6 h	183	79.5	206	6
SS1.5 h+HT60 min+LT12 h	189	73.5	186	5.75

DownLoad: CSV
